Dahili Mikrofon, 4MP Çözünürlük, H.265+ sıkıştırma teknolojisi, 120 dB WDR ile güçlü arka ışığa karşı net görüntüleme, Suya ve toza dayanıklı (IP67), Depolama için 128 GB’a kadar SD kart yuvası, EXIR 2.0, uzun IR mesafeli gelişmiş kızılötesi teknolojisi

Camera
Image Sensor 1/3″ progressive scan CMOS
Min. Illumination Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100, 000 s
Slow Shutter Yes
Day &Night IR cut filter
Wide Dynamic Range 120 dB
Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
DNR 3D DNR

Lens
Lens 2.8 mm, 4 mm
Aperture F2.0
Focus Fixed
FOV
2.8 mm, horizontal FOV 98°, vertical FOV 53°, diagonal FOV 115°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 91°
Lens Mount M12

Illuminator
IR Range Up to 30 m
Wavelength 850 nm

Video
Max. Resolution 2560 × 1440
Video Compression
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Video Bit Rate 32 Kbps to 8 Mbps

Smart Feature-Set
Region of Interest 1 fixed region for main stream

Image Enhancement HLC, BLC, 3D DNR
Image Setting
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client
software or web browser
Day/Night Switch Auto/Schedule/Day/Night
Main Stream Max. Frame Rate
50Hz: 20 fps (2560 × 1440)
25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20 fps (2560 × 1440)
30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream Max. Frame Rate
50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)

Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP,
IGMP, QoS, IPv6, UDP, Bonjour
API Open Network Video Interface (Profile S, Profile G), ISAPI, SDK

Simultaneous Live View Up to 6 channels
User/Host Up to 32 users, 3 levels: Administrator, Operator and User
Client iVMS-4200, Hik-Connect, iVMS-5200
Web Browser
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+
Alarm Trigger
Motion detection, video tampering, exception (network disconnected, IP address
conflict, illegal login, HDD error)

Interface
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB
Built-in Microphone -U: Yes
Hardware Reset -F: Yes

Compression Standard
H.264+ Main stream supports
H.265+ Main stream supports

General
Firmware Version V5.5.111
Web Client Language English, Ukrainian
General Function
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP
address filter
Startup and Operating
Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, Class 3)
Material Metal & Plastic
Dimensions
Camera: Ø110 mm × 85.3 mm (Ø4.3″ × 3.4″)
With package: 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
Weight
Camera: approx. 320 g (0.7 lb.)
With package: approx. 556 g (1.2 lb.)
Power Consumption and Current
12 VDC, 0.4 A, max. 5 W
PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 6.5 W
Interface Protection
IP67 (IEC 60529-2013), TVS 2000V lightning protection, surge protection and voltage
transient protection
